X-STATION
Suprema X-Station terminal for time and attendance records via contactless RFID with embedded FACE detector attracts with its elegance and ease of use. This ultra slim design device consists a series of functions such as RF card reader, PIN authentication capability, TCP/IP interface, and a range of comprehensive time recording capabilities.
Featuring a 3.5'' TFT display with embedded touch screen, an intuitive graphical user interface, this device offers exceptional capabilities to users and system administrators.
The X-station features a storage capacity up to 20,000 users and 1,000,000 records, and using FACE detector technology and embedded camera, X-Station can record up to 5,000 faces providing additional levels of security and eliminating potential user misuse of the system.
ADVANTAGES
- 3.5'' Touchscreen LCD
The Intuitive Graphic User Interface (GUI) enables higher quality and simple work for users and system administrators
- FACE detector technology and integrated camera
Features of the FACE Detector Technology for recording and facial images recording for the purpose of preventing "buddy punching"
- Four (4) function keys for time recording
Four different keys that can be adjusted depending on the required functions (input/output...) for faster, simple, and more efficient attendance records
- Strong processor
A 667 MHz processor provides fast and easy operation and data processing
Technical specifications X-Station
CPU | 667MHz RISC |
LCD | 3.5 inch touchscreen LCD |
MEMORY | 1GB Flash + 12 8MB |
RF READER | 13.56MHz Mifare, 125KHz EM |
USER CAPACITY | 200.000 users |
LOG CAPACITY | 1.000.000 logs |
FACIAL IMAGES CAPACITY | 5.000 logs |
INTERFACE | TCP/IP, 2CH RS485, Wiegand (in & out) 2 x TTL I/O, door relay |
SOUND | 16-bit Hi-Fi (voice & sound) |
OPERATING TEMPERATURE | -20’C ~ 50’C |
VOLTAGE | 12V DC |
DIMENSIONS | W79 X H135 X D21 mm |
CERTIFICATE | CE, FCC, KCC |
